Right now, the NanoPi R5S performance information is widely available in Chinese. Therefore, I decided to make this post, hope it will be useful if you are looking for this piece of information.
If you have yet to watch the NanoPi R5S detailed overview in English, you can find it here.
In the video, I am using the latest FriendlyWRT released on August 3, 2022. It is a fold of OpenWRT developed by Friendlyelec.
Testing Network Diagram
I setup a 2.5 Gigiabit network connection in order to test out the potential of the NanoPi R5S. The NanoPi R5S and the test server is connected to the FastRhino R68s LAN ports.
NanoPi R5S FriendlyWRT Performance
I run the WAN to LAN test a few times and the result is different from one to another. It looks like there are stability problem that FriendlyElec team need to fix.
For Wireguard VPN and OpenVPN, the result is stable. The OpenVPN throughput is at 150Mbps and Wireguard VPN is around 610 Mbps.
| Data Rate Unit: Mbps | OpenSpeedTest Download | OpenSpeedTest Upload | iperf3 |
| WAN to LAN | 1168 | 883 | 607 |
| WAN to LAN (SW Offloading) | 1853 | 1338 | 641 |
| OpenVPN | 160 | 148 | 150 |
| Wireguard VPN | 637 | 610 | 480 |
Testing Video
You can watch the full video to see how I upgrade the FriendlyWRT to the latest version as well as configuring the LAN1 port as a WAN port (2.5GbE).
Feeel free to let me know what is the test you want me to do next with the NanoPi R5S!
